Your current position ：Home >> Products >>
Product Introduction
Product Name：CW-140000A
Short Description：Model：CW-140000A   Bandwidth：5Hz~30MHz   Accuracy：1%+2mV
Detailed description ：
Type Sensitivity mV/A Peak Current (A) Min. Current ( A） Noise (mV Pk-Pk) Bandwidth (3db) Accuracy Coil Length Line Length
CW-140000A 0.05 140000 1400 5 DC-5Hz~30MHz 1%+2mV 300mm~1000mm 1m~4m
General characteristics
Coil cross section(Max) 3kV
Temperature Range -20℃-100℃
Coil cable diameter 1.8/3.5/4.5/8mm
Power supply DC Supply Adaptor 6V or Battery 4*AA
Size 170*86*30mm
